  HMGP-105N


PUMP SPEC. MOTOR SPEC.
  HMGP-105N HMGP-105M HMGP-103 HMGP-105C OUTPUT 36W
PUMP TYPE GEAR PUMP
DISCHARGE PRESSURE 8kg/cm² PHASE 1Ø
INTERVAL TIME 3~30/
30~120min		 30~120min 3~30/
30~120min		 외부제어
USING OIL 32~800(cSt) VOLTAGE 110V 200 / 220V
FILTER 80 Mesh CURRENT 0.85A 0.44A
TANK CAPACITY 2Liter FREQUENCY 50/60Hz
WEIGHT 2.5kg
FLOAT S/W - 접점형식 A 접점(NO)
- 유면하한시 ON
DISCHARGE AMOUNT 3~30/
4~80 cc		 4~45 cc 3~30/
4~80 cc		 100cc/min
OIL WARNING 주문사양 BUZZER 접점출력 BUZZER
